Produkcja piw rzemieślniczych
Alfa Laval oferuje urządzenia do produkcji piwa przeznaczone zarówno dla niezależnych lokalnych producentów jak i światowych browarów rzemieślniczych. Pozwalają one poprawić jakość piwa, optymalizować produkcję czy obniżyć koszty oraz zmniejszyć wpływ na środowisko.
Contact us
Solutions:
Intelligent Whirlpool System (IWS)
Whirlpool optimization system where trub is dried in a decanter centrifuge.
- Cut energy and water consumption.
- Minimize fouling/clogging in the wort cooler.
- Reduce the amount of trub in fermenters and cuts whirlpool time.
- Enable higher hop utilization from counter-current flushing of solids in the decanter.
Suitable for brew sizes larger than 50 hl (43 bbl).
Iso-Mix Mini
Rotary jet mixer for fermentation tanks or fast blending of liquid, powder and gas.
- Improves tank homogenization.
- Ideal for adjustment in BBT or soft drink preparation.
- Mobile unit that can be moved between tanks.
Up to 40% faster fermentation.
3-in-1 Yeast Propagation Module
Yeast handling system that lets you rehydrate, propagate, store and re-use yeast strains. The system is based on our extensive experience from yeast management and can be fully tailored to your needs.
Lowal de-alcoholizer
Module for dealcoholization of beer and generation of reverse osmosis (RO) water.
- Removes alcohol and water from your beer with a minimum loss of flavours.
- Make low-alcohol beer (below 0.5% v/v) with ease.
- Cold process.
- Suitable for RO water generation, so you get full control of your brewing water.
Carboset Mini
Automatic inline carbonation module for precise CO2 injection in your beers.
- Equalizes CO2 concentration in your batches.
- N2 available on request.
- Efficient, sanitary system that is easy to clean.
- Carboblend option: adjust your alcohol/Plato content with deaerated water.
- Store several recipes in the unit with individual settings for different beers.
Centrifugal separators
Introducing a centrifugal separator in your brewing process brings benefits such as:
- Higher production capacity without having to expand fermenting capacity.
- Clarifying beer when the flavor profile is just right.
- Reduce losses by up to 15% by separating out beer from the tank bottoms instead of draining it away.
Alfa Laval offers these plug-and-play separation modules.
All units feature large spaces for solids handling (IPA friendly). No need for deaerated water or CO2 to keep O2 levels low.
View our Brew Separator Selection Guide here.
Brew 20
- Top-fed axial-hermetic clarifier.
- Dimensions (LxWxH): 800 x 1,500 x 1,450 mm (31½ x 59 1/16 x 57 1/8 in.)
- Flow rate: 4-22 hl/h (3-19 bbl/h)
Brew 80
- Top-fed axial-hermetic clarifier.
- Dimensions (LxWxH): 1,815 x 975 x 1,545 mm (71½ x 38½ x 61 in.)
- Flow rate: 10-50 hl/h (8-40 bbl/h)
Brew 250
- Smallest center-to-center inlet-outlet polishing separator. Fully hermetic machine with low power consumption. Gentle product treatment and low temperature pick-up.
BSF Mini (Beer Sterile Filtration)
Beer sterile filtration module with 100% bacteria retention without thermal degradation. The gentle treatment guarantees taste is not affected in any way. For maximum safety, each membrane cartridge is certified and the system performs an integrity check before processing a batch.
There is no need for a buffer tank, meaning the footprint is small. An extra, standalone Clean-in-place (CIP) module is available.
Flexitherm Mini
Automatic pasteurization module designed to preserve your beer’s quality.
- Regulates and pasteurizes variable flows.
- Inactivates all bacteria and remaining yeast cells that risk spoiling your beer.
- No CO2 breakup during high temperature stage.
- Hygienic and compact design with stand alone PLC.
- Store several recipes in the unit with individual settings for different beers.
Let's meet
We understand that each brewery is unique. That is why we don’t offer any one-sizefits-all, out-of-the-box solutions. Before making any suggestions we always listen carefully to your requirements, goals and ambitions – and preferably have a taste or two of your beers.
We would gladly discuss the possibilities in your brewery and speak to you in person. Please contact us at craft@alfalaval.com ,
